Vinyl Grid Suspension System
Vinyl Grid Suspension System HGCG
Vinyl Grid Suspension System
100 sq. Feet
2 x 2 or 2 x 4 Layout
Available in 11 colors
Price
$142.99

* denotes required field

Grid Layout*
Grid Finish*

Product Description

BASIC USES / RELATED USES

  • PVC suspension ceiling assembly for interior and exterior high humidity and corrosive environments.
  • Solid vinyl construction eliminates rust and white corrosion.
  • Acoustic panels not included.

◦Please Note:

40% restocking fee for colored grid system orders.


◦ PRODUCT ATTRIBUTES AND CHARACTERISTICS

  • Suspended grid, lay-in type.
  • Keyhole operation makes installation simple.
  • Flexible to fit most 610 x 610 mm (24 x 24 inches) or 610 x 1220 mm (24 x 48 inches) flat lay in or revealed edge ceiling tile.
  • Available for standard thickness dimensional tile and tile/panel up to 38 mm (1-1/2 inch) thick.
  • Light and Intermediate duty class
  • Maximum weight 12 lbs. per linear foot (48 lbs. per square foot)

Each kit includes;
Part# 1 - 7 Mains (8 feet long ea.)
Part# 2 - 7 Mains Connectors
Part# 3 - 25 24" Tees
Part# 4 - 6 Wall Brackets (8 feet long ea.)

Installation Instructions (PDF 1mb)

HG-Grid Spec Sheet (PDF 171kb)

Frequently Asked Questions for Vinyl Suspension System

1. What is the minimum drop for Vinyl Suspension System?
2. What kinds of tiles can I use with Vinyl Suspension System?
3. What kind of application is Vinyl Suspension System recommended for?
4. What kind of lights can be used with Vinyl Suspension System?
5. What is a dry line?
6. In which direction do my mains need to be installed?
7. What tools do I need to install Vinyl Suspension System?
8. Do I need to align my room to have equal borders?
9. How do I install the wall brackets on inside corners?
10. Can I order more connector clips if needed?
11. How do I cut the border panels if I'm using a revealed tile?
12. How does the cross tee attach to the wall bracket?
13.Can Vinyl Suspension System be used outdoors?

1. What is the minimum drop for Vinyl Suspension System?
The minimum drop for Vinyl Suspension System is 4 inches. This is to allow you enough
room to slide and drop the tile in place.

2. What kinds of tiles can I use with Vinyl Suspension System?
With the Vinyl Suspension System system, any 15/16-inch 2x2 or 2x4 flat or revealed
tile can be used. (Revealed panels are those with the 1/4-inch lip around the edge of the
panel).

3. What kind of application is Vinyl Suspension System recommended for?
Vinyl Suspension System is recommended for basements, bathrooms, dining rooms and
kitchens. Since Vinyl Suspension System is made of PVC plastic, the grid will not rust in
high humidity areas.

4. What kind of lights can be used with Vinyl Suspension System?
Any type of recessed lighting can be used with Vinyl Suspension System. However, any
type of lighting you choose to use, must be mounted to or suspended from the floor joists
and NOT the ceiling grid. Since Vinyl Suspension System is made of PVC plastic, the
grid cannot withstand the weight of the lighting without bending the grid components.

5. What is a dry line?
A dry line is a string line run from one end of the room to the other. It is an alternative
to snapping chalk lines. In such cases where you need to snap a chalk line to align your
cross tees, you may need to run a dry line if the cross tees fall between the floor joists
instead of on a floor joist.

6. In which direction do my mains need to be installed?
The Mains can be installed in either direction. If 2'x4' trouffer lights are being used, the
mains should be installed parallel to the side of the light.

7. What tools do I need to install Vinyl Suspension System?

•String or Chalk Line
•Drill with Phillips Tip
•Tape Measure
•Tin Snips
•Utility Knife
•1” Dry Wall Screws
•Hanger Wire & Lag Eyes

8. Do I need to align my room to have equal border tiles?
The Room Planning section of the installation guide goes through step-by-step
instructions on how to lay out your room with equal border tiles, giving you a more
professional look. However, you do not necessarily need to have equal border tiles. You
can start a room with a full panel and cut tiles only on one side.

9. How do I install the wall brackets on inside corners?
To install the wall bracket on an inside corner, you can either abut the two wall brackets
together, or you can miter them at 45 degrees.

10. Can I order more connector clips if needed?
Each Vinyl Suspension System main comes with one connector clip. The connector clips
attaches the end of one main to the beginning of another. The connector clips that are
included with the mains should be sufficient to finish your room.

11. How do I cut border panels if I’m using a revealed tile?
On the revealed panels you will notice a ¼” lip around the edge of the tile. If you need
to cut a border panel, you first need to cut the panel down to the border size you have
calculated. To do this, measure from the wall to the front edge of the cross tee; then, lay
the tile on the grid. Score the face of the tile along the edge of the wall bracket and pull
the tile out of the grid. Run a utility knife along a straight edge cutting into the tile. Then
cut into the side of the panel dropping out the corner of the tile.

12. How does the cross tee attach to the wall bracket?
The Tee is not attached to the wall bracket in any way. It simply rests on the leg of the
wall bracket.

Available in a wide range of colors and finishes, the HG-Grid can handle high-humidity or corrosive environments other systems would fail in. View the color chart and select your choice from the drop down menu. These are pictures of the actual material and they look amazing.
